Leaked full/detailed Leica Q3 camera specifications:
(Via Leicarumors, digicame-info)
Rumors say price should be around 5,980 Euros.
-------------
PDF file: https://drive.google.com/file/d/1B3hgLU7rHiNNhnZNzVdel_dUx2O1V_kt/view
Camera type
Digital 35mm compact camera
Sensor size
CMOS sensor, 62.39 MP/60.3 MP (total/effective)
Processor
Leica Maestro series (Maestro IV)
Filter
RGB color filter, UV/IR filter, no low-pass filter
File formats
Photo: DNG (raw data), DNG + JPG, JPG (DCF 2.0, Exif 2.31) Video:
MP4
h.265: AAC, 48 kHz/16 bit
h.264: AAC, 48 kHz/16 bit
MOV
h.265: LPCM 28 kHz/24 bit
h.264: LPCM 28 kHz/24 bit
ProRes: LPCM 28 kHz/24 bit
Image resolution DNG
9520 x 6336 pixels (60.3 MP) 7404 x 4928 pixels (36.5 MP) 5288 x 3518 pixels (18.6 MP) JPG
9520 x 6336 pixels (60.3 MP) 7392 x 4928 pixels (36.4 MP) 5280 x 3512 pixels (18.5 MP)
File size
DNG: approx. 70 MB, depending on resolution and image content JPG: depending on resolution and image content
Video: max. length: 29 min
Color depth DNG: 14 bit
JPG: 8 bit Color space
Photo: sRGB
Video Resolution Resolution:
C8K (17:9): 8192 x 4320
8K (16:9): 7680 x 4320
C4K (17:9): 4096 x 2160
4K (16:9): 3840 x 2160
Full HD (16:9): 1920 x 1080
Buffer memory 8GB
Capacity, depending on frame rate and picture format, estimated quantity (number of possible images in the buffer memory)
15 fps:
DNG: 63
DNG + JPG: 63 JPG: 67
9 fps:
DNG: 70
DNG + JPG: 66 JPG: 76
7 fps:
DNG: 74
DNG + JPG: 69 JPG: 83
4 fps:
DNG: 83
DNG + JPG: 72 JPG: 104
2 fps:
DNG: 164
DNG + JPG: 88 JPG: 947
Storage medium
UHS-II (recommended), UHS-I, SD/SDHC/SDXC memory card
Material
Full metal housing: magnesium die-cast, leather covering, protection type IP52
Operating conditions
0 Degree C to +40 Degree C
Interfaces
ISO accessory shoe with additional control contacts for Leica flash units, HDMI jack Type D, USB 3.1 Gen 2 Type C up to 10 Gbps
Tripod thread
A 1/4 DIN 4503 (1/4″ with stainless steel in the base
Designation
Leica Summilux 28 f/1.7 ASPH., 11 lenses in 9 segments, 3 aspherical lens areas
Lens filter thread E49
Digital zoom
Optionally approx. 1.25x (equivalent to 35mm), approx. 1.8x (equivalent to 50mm), approx. 2.7x (equivalent to 75mm), or approx. 3.2x (equivalent to 90mm)
Image stabilization
Visual compensation system for photos and video recordings
Aperture range
F1.7 to F16 in 1/3 EV increments
Viewfinder (EVF)
Resolution: 5,760,000 dots, 120 fps, magnification: 0.79x at aspect ratio: 4:3 / 0.76x at aspect ratio: 3:2, frame coverage:
100%, exit pupil position: 20.75mm, setting range -4/+2 dpt, with eye sensor for automatic switchover between viewfinder and LCD panel, time delay 0.005 s
LCD panel
3″ TFT LCD, approx. 1,843,200 dots, 384 ppi, aspect ratio 3:2, touch panel
Shutter type
Mechanical central shutter or optional electronic shutter
Shutter speeds
Mech. shutter: 120 s to 1/2000 s
Electro. shutter function: 1 s to 1/16000 s Flash Synchronization: up to 1/2000 s
Shutter button Two-stage
(1st stage: Activation of the camera electronics including autofocus and exposure metering, 2nd stage: Taking the picture)
Self-timer
Delay time: 2s or 12s
Drive Mode
Single, Interval Shooting, Exposure Bracketing
Continuous shooting:
Continuous – 2 fps / 14 bit / AF, Continuous – 4 fps / 14 bit / AF: Automatic settings (exposure settings in operating modes P/A/S, automatic white balance and autofocus) are implemented individually for each frame.
Continuous – 7 fps / 14 bit, Continuous – 9 fps / 12 bit, Continuous – 15 fps / 12 bit:
Automatic settings (exposure settings in operating modes P/A/S, automatic white balance and autofocus) are implemented for the first frame, and are then applied for each subsequent frame in the same picture series.
Focus range
30cm to Infinite
With macro setting: from 17cm
Focus mode
Automatic or manual
With manual setting: optional magnifying glass function (Auto Magnification) and edge marking (Focus Peaking) available as focus assist
Autofocus system
Hybrid-AF due to combination of contrast metering, depth mapping, and phase comparison metering with AF metering points in the sensor.
Autofocus modes
Intelligent AF (autonomously selects AFs and AFc), AFs, AFc, AF setting can be saved, optional Touch AF
Autofocus metering methods
Spot (can be shifted), Field (can be shifted and scaled), Multi-Field, Zone (can be shifted), Eye/Face/Body Detection, Eye/Face/Body + Animal Detection, Tracking
Autofocus metering fields 315
Exposure metering
TTL (exposure metering through the lens), with working aperture
Metering principle
Exposure metering is done by the image sensor for all exposure metering methods (in Live View mode and in rangefinder mode)
Exposure metering methods
Spot, Center-Weighted, Highlight-Weighted, Multi-Field
Exposure modes
Program AE mode (P)
Aperture-priority mode (A): manual aperture setting Shutter-priority mode (S): manual shutter-speed setting Manual (M): manual setting for shutter speed and aperture Various fully automated variants (Scene Mode):
Auto, Sport, Portrait, Landscape, Night Portrait, Snow/Beach, Fireworks, Candlelight, Sunset, Digi scoping
Exposure compensation
+/-3 EV in 1/3 EV increments
Automatic bracketing
3 or 5 frames, graduations between shoots up to 3 EV, in 1/3 EV increments
additional optional exposure compensation: up to +/-3 EV
ISO sensitivity range Auto ISO
Photo: ISO 100 to ISO 100 000 Video: ISO 100 to ISO 100 000 Manual
Photo: ISO 50 to ISO 100 000 Video: ISO 50 to ISO 100 000
White balance
Automatic (Auto), default (Daylight, Cloudy, Shadow, Tungsten, Flash), manual metering (Gray card) , manual color temperature settings (Color Temperature, 2000 K to 11500 K)
Flash unit connector
Via the accessory shoe
Flash sync time
1/2000 s, slower shutter speeds available, automatic changeover to TTL linear flash mode with HSS-compatible Leica system flash units if sync time is undercut
Flash exposure metering
Using center-weighted TTL pre-flash metering with Leica flash units (SF 26, SF 40, SF 58, SF 60, SF 64) or with system-compatible flash units, remote controlled flash SF C1
Flash exposure compensation
SF 40: +/-2 EV in 1/2 EV increments SF 60: +/-2 EV in 1/3 EV increments
Microphone Stereo
Speaker Mono
Bluetooth
Bluetooth 5.0 LE: Channel 0-39 (2402-2480 MHz), maximum output (e.i.r.p.): 10 dBm
GPS
Not available everywhere due to country-specific legislation; can be added via the Leica FOTOS app. Data is written to Exif header of the picture files.
Menu languages
English, German, French, Italian, Spanish, Portuguese, Russian, Japanese, Traditional Chinese, Simplified Chinese, Korean
Rechargeable battery (Leica BP-SCL6)
Lithium-ion rechargeable battery, rated voltage: 7.2 V (DC); capacity: 2200 mAh (min.), 350 shots (based on CIPA standard, with All Displays Auto Off = 5 s); manufacturer: Panasonic Energy (Wuxi)
Charger (Leica BC-SCL4)
Input: AC 100-240 V, 50/60 Hz, 0.25 A, automatic switchover; output: DC 8.4 V 0.85 A; manufacturer: Salom Electric (Xiamen)
Charging via USB
During operation: 9 V/3 A (min. 27 W)
With camera switched off: 5 V/1500 mA (2.5 W or greater)
Wireless Charging
Optimal performance with 9 V chargers (10 W Charging Pad required)
Rated values for input voltage/power
7.2 V 2.3 A (battery), 5 V 3.0 A / 9 V 2.5 A (USB)
Battery Info
Required, included
Battery Material Lithium ion
Battery Type Non-universal
Battery Quantity 1
Dimensions
130 x 92.6 x 80.3mm
Weight
With Battery: 743g (Approx.) Without Battery: 658g (Approx.)
|
