pbraymond wrote:
Rafael, that Rayfact lens is incredibly sharp and a great performer. I always thought adding extension would take away from infinity focus, not the opposite. There must be an existing extension original to the lens that is longer than the one you are using now. Always enjoy you cruising shots.
Ray, this is how it works: Lens is a micro lens for the F mount (there are many other industrial lens mounts that this lens is made for). The F model 90mm 4 goes from .05 to .5x magnification on a F camera or F DSLR, cannot focus beyond 5 feet or so. IF mounted on a Z camera with an FTZ adapter it would be the same situation, not focus past 5 feet or so. However if mounted on the Z camera with a shorter extension than the FTZ it will focus to infinity. My combination of K3, K4 and 52mm to Z adapters are shorter than the FTZ.
The lens performs so well precisely because it has a low magnification of .05X and uses floating elements, it only has to move a short distance closer to the sensor for infinity, keeping the excellent image quality.
Not all is perfect, aside from being heavy, it does not use helicoids, it uses cams, very accurate but needs careful slow focusing to get the sharpest photo.
Also, I was lucky to find an early lens in perfect condition and here in the US, it must have been used in a clean room and has no marks or dust. Most lenses like this one will come from decommissioned factory equipment and may not be in as good a shape.
