raboof wrote:
I’ll look and see how I did it. It’s been a while. If I remember it correctly, I had to rotate the focus ring to make room for the lever to pull out.
rafaelcasd wrote
Need help!!!!!
Started to install the AI kit on the 300mm 4.5K, yes I do have the JIS screwdrivers.
HOWEVER, the aperture lever stays on the bayonet mount and does not allow that to be removed. I am sure there is a trick to separate these two.
Do you know what to do?? Chuong, you can do this with your eyes closed, please explain to me.
Thanks!
Thank you Chuong, you are correct, one must focus the lens close to make room for the fork lever to release. Placed the Finnish ai kit No. 54 ring on the lens. Tested the lens in the D810 at max frame rate and it gave me even exposure at all apertures.
Took advantage of the disassembly to clean all parts and apply a tiny bit of Dow Corning high vacuum grease to the helicoid. (this grease does not outgas, it is meant to not contaminate experiments or work in high vacuum)
AI conversion is done, now just to enjoy the 300mm 4.5 ED K ai converted lens!!!!!!
Respectfully
Rafael
