Phong.nh wrote:
rolubich wrote
Phong.nh wrote
I have a PC-Nikkor 35mm f/2.8 tilt lens.
Can you explain what is the second ring for - I’m not sure about. Rotating it makes the viewfinder look brighter or darker. The lens is a pre-set one, it means that the diaphragm does not stay always wide open and stop down to the set aperture just before the shot, but it stay at the value set on the second (from the front of the lens) thin ring.
The first (from the front of the lens) thin ring is an aperture limiter, it means that if it is set to f/8 the second ring can go from fully open to f/8.
This is to allow you to set the desired aperture on the first ring, than to move the second ring from the wide open aperture (that is supposed the aperture you want to use in order to have a brighter view and focus more easily) and than set the desired aperture moving the second ring quickly to the mechanic stop of the aperture limiter just before the shot, so you don't have to count the step or look at the aperture scale.
Hope that is clear. Thanks rolubich, all clear to me now.
High quality glass even tilt function ignored.
Phong, it is also a great lens for panos when used on a tripod. By using the tilt mechanism horizantally you can overlap images by about a third without vignetting. Great for including wider buildings without moving a tripod. I'll repost an old image below.
