Archive 2008 · Yet another Canon FL55 1.2 to EOS convert

wiregen
Offline
Buy and Sell: On

p.2 #1 · Yet another Canon FL55 1.2 to EOS convert

I'm really surprised with Alf's image samples vs yours Jim. Chroma is definitely present, I think it could be partly with the lens design.

I was chatting with Jim regarding conversion of the 50mm 1.2L FD

Like the 50mm 1.2 SSC aspherical The rear element is considered the "floating" element. This element is crucial to retain the sharpness and reduce chroma on the aspherical FD lenses. Problem is on how to mount this.

I'm still trying to find a solution. I was thinking machining off the rest of the rear element mount, but the question is how much. I don't currently have the time to keep experimenting with it. But, I figured it anyone dares attempt to convert FD mounts to be aware of the difficulty.

I posted some test shots I took without the rear element below.

Here's it mounted on my 5D. It does go over infinity so a spacer needs to be added.

Oct 01, 2008 at 08:18 AM

cogitech
Offline
Buy and Sell: On

p.2 #2 · Yet another Canon FL55 1.2 to EOS convert

JimBuchanan wrote:

As per suggestion of tmessenger in the above issue of “pink fringing”, to eliminate any flare or reflections caused by light bouncing around the mirror box with wide apertures, or brighter scenes, or closer distances where the lens assembly moves out front and exposes the stock chrome threads of the M42-EOS adapter, certain areas were painted flat black to eliminate reflections.

This image is copyrighted by the owner

I always do this when converting Rokkors, etc. Some flat black Tremclad works great.

Oct 01, 2008 at 01:08 PM

Alf Beharie
Offline
Image Upload: Off

p.2 #3 · Yet another Canon FL55 1.2 to EOS convert

JimBuchanan wrote:
An addendum to this thread shows a refinement of my method of Canon FL 55 1.2 lens conversion. As I was hired to convert another lens, I took the opportunity to turn down the helicoid assembly as described by Alf Beharie. The benefit of this is not only better precision, but eliminating the need of a spacer between the lens and m42-EOS adapter, and not having to mess with the helicoid mechanism at all.

Shown, is the rear of the helicoid assembly and M42-EOS adapter, after 2mm was removed. The infinity focus stop is also seen with the 3 slot screws, and was ultimately used to fine tune infinity.

This image is copyrighted by the owner

As per suggestion of tmessenger in the above issue of “pink fringing”, to eliminate any flare or reflections caused by light bouncing around the mirror box with wide apertures, or brighter scenes, or closer distances where the lens assembly moves out front and exposes the stock chrome threads of the M42-EOS adapter, certain areas were painted flat black to eliminate reflections.

This image is copyrighted by the owner

Question is, has painting those areas matt black actually made any difference to the resulting images?

Oct 01, 2008 at 06:37 PM

Alf Beharie
Offline
Image Upload: Off

p.2 #4 · Yet another Canon FL55 1.2 to EOS convert

manowar wrote:
I have both of the lenses, FL and Rokkor. Didnt have a chance for a proper test but from the results taken from both lenses, the Rokkor is obviously much much far better than the FL55, IMHO.
Sorry to say but I found nothing amazing from this FL55 but it's still a keeper.

Oct 01, 2008 at 06:47 PM

Ed Sawyer
Online
Buy and Sell: On

p.2 #5 · Yet another Canon FL55 1.2 to EOS convert

the FL seems to have a lot more coma wide open, at least.

Oct 02, 2008 at 05:05 PM

hibernum
Offline
Image Upload: Off

p.2 #6 · Yet another Canon FL55 1.2 to EOS convert

Interesting work. I am still trying to remove the front trim ring to get at the infinite stop, with no luck. Are you guys using any special tools, because it doesn't seem like it will budge. Thanks much.

Oct 13, 2008 at 05:49 PM

tmessenger
Offline
Image Upload: On

p.2 #7 · Yet another Canon FL55 1.2 to EOS convert

I use a plastic pvc pipe with a rubber inner tube over the end of it. This will give you enough traction on the trim ring to get it to turn loose.

tm

Oct 13, 2008 at 08:04 PM

tmessenger
Offline
Image Upload: On

p.2 #8 · Yet another Canon FL55 1.2 to EOS convert

I'm getting OK results with my FL55 wide open.

tm

Ed Sawyer wrote:
the FL seems to have a lot more coma wide open, at least.

This image is copyrighted by the owner

Oct 13, 2008 at 08:21 PM

manowar
Offline
Image Upload: Off

p.2 #9 · Yet another Canon FL55 1.2 to EOS convert

Few snaps bokeh test

This image is copyrighted by the owner

Oct 13, 2008 at 10:03 PM

Empire
Offline
Image Upload: Off

p.2 #10 · Yet another Canon FL55 1.2 to EOS convert

tmessenger,
I'd say that that is more than just ok results. It looks very much like rokkor sharpness to me and it certainly has smooth bokeh!

Holding my un converted FL 55/1.2 infront of my 20d gives results that look every bit as good as my rokkor. Infact i have a suspicion that with my particular copies the FL is actually the better performer... it certainly delivers more consistant results throughout the f stops.

not bad for a lens I paid US$65 for with a 'free' FT QL...

just my 2p

Oct 14, 2008 at 03:13 AM

Dim.ka_
Offline
Image Upload: Off

p.2 #11 · Yet another Canon FL55 1.2 to EOS convert

Here is canon fd version
This image is copyrighted by the owner

Minolta

Alf please understand - Sigma sd14 Foveon gives that character that you have with your canon lense.
On 5D perfomance of this canon lense is not stellar

http://www.flickr.com/photos/convert1/page2/

The other thing i am not using rokkor 58 1.2 on Sigma anymore - the reason is simple - f1.2 on such crop 1.7 useless instead i have converted minolta md 50mm f1.7 and will do minolta md 35mm f1.8 convertion.

Oct 14, 2008 at 08:18 AM

JimBuchanan
Offline
Buy and Sell: On

p.2 #12 · Yet another Canon FL55 1.2 to EOS convert

Dim.ka_, do you have the other pages to these lens tests? Canon FD 50L, for example? Or, the FD 50/1.2 aspherical?

Oct 14, 2008 at 09:21 AM

Dim.ka_
Offline
Image Upload: Off

p.2 #13 · Yet another Canon FL55 1.2 to EOS convert

Yes i have the whole test, but there are no other canon lenses.

Oct 14, 2008 at 10:11 AM

Alf Beharie
Offline
Image Upload: Off

p.2 #14 · Yet another Canon FL55 1.2 to EOS convert

Dim.ka_ wrote:
Here is canon fd version
This image is copyrighted by the owner

Minolta

Interesting charts. Is the 55mm f1.2 SSC listed the aspherical version?

Alf please understand - Sigma sd14 Foveon gives that character that you have with your canon lense.
On 5D perfomance of this canon lense is not stellar

http://www.flickr.com/photos/convert1/page2/

The other thing i am not using rokkor 58 1.2 on Sigma anymore - the reason is simple - f1.2 on such crop 1.7 useless

Why do you think its useless?

Oct 14, 2008 at 08:22 PM

Dim.ka_
Offline
Image Upload: Off

p.2 #15 · Yet another Canon FL55 1.2 to EOS convert

The rear lense is so big in diameter that you can not see any difference between 1.2 and 1.8 - from f2 you can say that aperture blades start working.
So decide to convert smaller lenses. Already done MD 50mm 1.7

This image is copyrighted by the owner

tommorow will do md 35mm 1.8

This image is copyrighted by the owner

Oct 14, 2008 at 08:45 PM

ovredal73
Offline
Image Upload: Off

p.2 #16 · Yet another Canon FL55 1.2 to EOS convert

Good luck, Dmitry. Show us some images with that 35 Rokkor when its done

Oct 14, 2008 at 10:02 PM

Ed Sawyer
Online
Buy and Sell: On

p.2 #17 · Yet another Canon FL55 1.2 to EOS convert

I've done 2 of the MC Rokkor-HH 35 1.8s, it's a nice lens. haven't done the smaller MD version yet.

Another one I was thinking of was the vivitar 35 1.9. It came in several mounts, some of which probably don't even need converting.

-Ed

Oct 15, 2008 at 01:59 AM

Dim.ka_
Offline
Image Upload: Off

p.2 #18 · Yet another Canon FL55 1.2 to EOS convert

ovredal73 thanks, well, this small 35mm MD version will sit on sigma sd14.

This image is copyrighted by the owner

For 5D will go this one HH version

This image is copyrighted by the owner

Oct 15, 2008 at 07:41 AM

Anden
Offline
Image Upload: On

p.2 #19 · Yet another Canon FL55 1.2 to EOS convert

Alf Beharie wrote:
manowar wrote:
I have both of the lenses, FL and Rokkor. Didnt have a chance for a proper test but from the results taken from both lenses, the Rokkor is obviously much much far better than the FL55, IMHO.
Sorry to say but I found nothing amazing from this FL55 but it's still a keeper.

So far, I have'nt seen a single sample from the Rokkor where it shows any gain in IQ over the FL...I wonder if you are using your FL via one of those IQ reducing FL/FD-EF optical adapters?...That would explain the poor results you are getting with your FL. Would it be possible for you to post some head to head comparison pics?

Alf, for your own credibility on the forum you are almost required to get yourself a rokkor and shoot it side by side with your great copy of the FL. Thus we all can see what you see. I do not question the greatness of the FL but I do question the claimed superiority of the FL over the Rokkor.

Did the Rokkor bully you in your younger days?

Kind regards

Andreas

Oct 15, 2008 at 08:52 AM

convert
Offline
Image Upload: Off

p.2 #20 · Yet another Canon FL55 1.2 to EOS convert

Dim.ka wrote:
For 5D will go this one HH version

This Minolta 1,8/35mm HH is a great lens, I already converted it and works very well on 5D.
http://www.flickr.com/photos/convert1/

Kind regards

Oct 15, 2008 at 01:43 PM

Ed Sawyer
Online
Buy and Sell: On

p.2 #21 · Yet another Canon FL55 1.2 to EOS convert

Nice shots, Convert! I like this lens a lot too, have converted a couple so far. I don't have a shaved mirror so it does hit @ infinity, but I can get out to 20-30ft without hitting.

-Ed

Oct 15, 2008 at 04:16 PM

convert
Offline
Image Upload: Off

p.2 #22 · Yet another Canon FL55 1.2 to EOS convert

Hi Ed, to get infinity with 1,8/35mm HH was not easy for me (protrude more than Rokkor 1,2/58mm), it means you have to shave the mirror on 5D more than normal".

Kind regards

Oct 15, 2008 at 04:59 PM

ovredal73
Offline
Image Upload: Off

p.2 #23 · Yet another Canon FL55 1.2 to EOS convert

Convert, that is a serious amount of work converting all those lenses! Impressive

Oct 15, 2008 at 06:20 PM

tmessenger
Offline
Image Upload: On

p.2 #24 · Yet another Canon FL55 1.2 to EOS convert

Oct 15, 2008 at 10:01 PM

convert
Offline
Image Upload: Off

p.2 #25 · Yet another Canon FL55 1.2 to EOS convert

ovredal73 wrote:
Convert, that is a serious amount of work converting all those lenses! Impressive

I appreciate your kindness, a lot of work was behind all the lenses which I converted.

http://www.flickr.com/photos/convert1/
Kind regards

Oct 16, 2008 at 03:34 PM
