Archive 2005 · Reversed lens info.



Tom Hicks
Offline
• • • • • • •
Upload & Sell: On
p.2 #1 · Reversed lens info.


You can take the same epoxy and fill part of the cap back with it then drill a hole where the pin on the body goes in.

Not the best pic but you'll get the idea.



May 22, 2005 at 05:15 PM
Monoman
Offline
• •
Upload & Sell: Off
p.2 #2 · Reversed lens info.


aww.. I see. Have you seen this?

wow

Edited by Monoman on May 29, 2005 at 05:06 PM GMT



May 22, 2005 at 07:41 PM
siddharth
Offline

Upload & Sell: Off
p.2 #3 · Reversed lens info.


Tom:
Does the reversed 28mm lens give the same working distance as the 50mm reversed (around 4 inches) ? Or does it give more working distance ?



May 22, 2005 at 08:16 PM
Tom Hicks
Offline
• • • • • • •
Upload & Sell: On
p.2 #4 · Reversed lens info.


Monoman wrote:
aww.. I see. Have you seen this?

wow



Thanks Mitch, yes it's been around a while , works good on eos lens , the way i'm showing is for those newbies that may not have the money for the other set up , put old lens to good use , and just make this old time macro alternitive aware to the younger crowd.



May 22, 2005 at 09:12 PM
Tom Hicks
Offline
• • • • • • •
Upload & Sell: On
p.2 #5 · Reversed lens info.


siddharth wrote:
Tom:
Does the reversed 28mm lens give the same working distance as the 50mm reversed (around 4 inches) ? Or does it give more working distance ?


No the 28 is around half of the 50 , the smaller the lens the closer you have to get.



May 22, 2005 at 09:14 PM
Juananguerrero
Offline

Upload & Sell: Off
p.2 #6 · Reversed lens info.


Well, in Spanish, but we see if it serves as aid. Around a 75% of my macro photos are done with reversed lenses, but... i cannot recommend it, is a nightmare.
Reversed lenses
Sorry for my english



May 23, 2005 at 06:28 PM
Monoman
Offline
• •
Upload & Sell: Off
p.2 #7 · Reversed lens info.


Hey Tom, now that you have experience in the reversed lens macro and the 180, which to you prefer? It seems to me that you get more dof with the reversed lens at the sacrifice of working distance.

Thanks!



May 23, 2005 at 06:45 PM
Netgarden
Offline
• • • •
Upload & Sell: Off
p.2 #8 · Reversed lens info.


Fantastic tutorial, thanks Tom.


May 23, 2005 at 09:53 PM
Dysfunctional
Offline

Upload & Sell: Off
p.2 #9 · Reversed lens info.


Ok, I'm confused. If you lock that lever up, wouldn't that keep the lense wide open no matter what the f-stop ring was set to?


May 27, 2005 at 06:47 PM
spink
Offline
• • •
Upload & Sell: Off
p.2 #10 · Reversed lens info.


Tom,

Thank you for this, I would have never thought to try it.

I have a 300D, I hand held the 18-55 kit lens backwards on the body (at 55)and was able to take a couple very quick (10 min before work) test shots.

Watch test

Now to rig up a mount.

Thanks again.



May 29, 2005 at 01:15 AM
rocketpop
Offline
• • •
Upload & Sell: Off
p.2 #11 · Reversed lens info.


Tom Hicks wrote:
Thanks Mitch, yes it's been around a while , works good on eos lens , the way i'm showing is for those newbies that may not have the money for the other set up , put old lens to good use , and just make this old time macro alternitive aware to the younger crowd.


You can BUILD the novoflex thing for pretty cheap. You need a cheapo extension tube (smallest generic you can find) a body cap and filter to make a reverse adapter, a rear-lens cap, and some wire.

Build a Reverse Lens that Retains Automatic Aperture Etc.



May 29, 2005 at 03:54 PM
rocketpop
Offline
• • •
Upload & Sell: Off
p.2 #12 · Reversed lens info.


Any idea if the old Konica lenses will work well reversed? I've got my eye on a 28mm Hexagon.


May 29, 2005 at 03:55 PM
pyrobrainiac
Offline
• •
Upload & Sell: Off
p.2 #13 · Reversed lens info.


any prime lens will work reversed. faster lenses are just heavier, since you'll likely just be shooting at f/11 or so anyway...


May 30, 2005 at 12:50 AM
rocketpop
Offline
• • •
Upload & Sell: Off
p.2 #14 · Reversed lens info.


Well, the problem with the konica is that it is a manual lens, but has "fully automatic aperture".

I'm afraid I won't be able to manually adjust the aperture.



May 30, 2005 at 09:50 PM
rocketpop
Offline
• • •
Upload & Sell: Off
p.2 #15 · Reversed lens info.


Focus manually?

I've never touched my focus ring. I just either get a bit closer or back away. Does anyone actually use the focus ring?



May 31, 2005 at 08:50 AM
rocketpop
Offline
• • •
Upload & Sell: Off
p.2 #16 · Reversed lens info.


I just ordered the canon 28mm FD F2.8 for $19. Seemed like a good deal.


May 31, 2005 at 09:56 AM
siddharth
Offline

Upload & Sell: Off
p.2 #17 · Reversed lens info.


rocketpop wrote:
I just ordered the canon 28mm FD F2.8 for $19. Seemed like a good deal.

Thats a good price. If you dont mind my asking, where did you order it from ?



May 31, 2005 at 10:55 AM
rocketpop
Offline
• • •
Upload & Sell: Off
p.2 #18 · Reversed lens info.


siddharth wrote:
Thats a good price. If you dont mind my asking, where did you order it from ?


It was an ebay deal "buy it now". It was just listed a couple hours before I bought it. Maybe I got lucky.

Also, I didn't mention why it was so cheap. It has all the original box, caps etc, HOWEVER... Its missing the front plate that helps protect the lens a bit and reduce flare. The filter threads are still there, but the lens part that says "Canon" etc is missing. Otherwise it is in great condition. I don't need the front plate because it'll be reversed anyway.



May 31, 2005 at 12:36 PM
Charlemagne
Offline
• • • •
Upload & Sell: Off
p.2 #19 · Reversed lens info.


I am going to get my lens this week, what I want to know is what tools were used to cut the hole in the body cap and what kind of glue or epoxy was used (I am not too handy, I feel overwhelmed when I just go to home depot..)

Charles



May 31, 2005 at 11:53 PM
Tom Hicks
Offline
• • • • • • •
Upload & Sell: On
p.2 #20 · Reversed lens info.


charles you can get a hole saw for your drill , and clean it up with a rattail file if need be , then go to the paint dept where the glues are and get some reg. JB weld epoxy.


Jun 01, 2005 at 12:33 AM
