Archive 2017 · Imaging the ISS



cameron12x
Offline
• • • •
Upload & Sell: On
p.1 #1 · Imaging the ISS


For those who have imaged the ISS, what body/lens combination did you use?

In that context, what ISO/shutter speed did you also use? Did you bracket?

TIA.



Sep 25, 2017 at 06:23 PM
runamuck
Offline
• • • • • •
Upload & Sell: On
p.1 #2 · Imaging the ISS


Hubble?


Sep 25, 2017 at 07:00 PM
johnsarra
Offline
• •
Upload & Sell: Off
p.1 #3 · Imaging the ISS


Quite a few astrophotographers have done this, but I have not tried. Here is one website: http://www.esa.int/Our_Activities/Human_Spaceflight/International_Space_Station/Your_International_Space_Station_photos

And this one: http://blogs.discovermagazine.com/badastronomy/2011/02/28/ridiculously-awesome-pic-of-discovery-and-the-iss-taken-from-the-ground/#.WcmZQoWcGUk



Sep 25, 2017 at 07:01 PM
msalvetti
Offline
• • • •
Upload & Sell: On
p.1 #4 · Imaging the ISS


Romy (Liquidstone) has done it with a 400mm plus two 2x TCs:
https://www.fredmiranda.com/forum/topic/1400625/0#13310844
http://photography-on-the.net/forum/showthread.php?t=910009

Also check out Thierry Legault's work:
http://www.astrophoto.fr/

Mark




Sep 25, 2017 at 07:14 PM
RobAmy
Offline
• • • • • •
Upload & Sell: On
p.1 #5 · Imaging the ISS


Here is one I attempted

EF800mm f/5.6L IS USM +1.4x III

ƒ/9.0
1120.0 mm
1/500
10000

International Space Station by A & R Photography, on Flickr



Sep 25, 2017 at 07:29 PM
jforkner
Offline
• • •
Upload & Sell: Off
p.1 #6 · Imaging the ISS


I caught it with my 6D + 100-400 II @ 400mm & f/5.6, ISO 6400, 1/2000s. Obviously not with same detail as above.

Jack



Sep 25, 2017 at 07:45 PM
Liquidstone
Offline
• • • •
Upload & Sell: Off
p.1 #7 · Imaging the ISS


cameron12x wrote:
For those who have imaged the ISS, what body/lens combination did you use?

In that context, what ISO/shutter speed did you also use? Did you bracket?

TIA.


1. Get the big white with the largest front element you can put your hands on, stack TCs on it until it's about f/16 or so, then shoot a bit stopped down at f/20 or f/22 to lessen aberrations.

2. Don't worry about diffraction, the atmosphere will be the limiting variable, and you need all the magnification you can get.

3. Focus manually, prefocus on a star or at the moon shortly before the ISS pass.

4. Use IS mode 2 if the lens is equipped to lessen shake due to panning.

5. Shoot at high ISO to get a shutter speed of 1/640 sec (if with IS), or 2 - 3 stops faster without IS. The ISS has no fine detail that can be resolved given the atmospherics, hence you can denoise like crazy during PP. The noise in the black sky can be easily masked out later.

6. Shoot in bursts at fastest frame rate to increase the chances of "getting through" at clearer spots of the atmosphere.

7. Use a DSLR with the highest pixel density available for maximum reach.

Here's one old attempt at the ISS, shooting data are listed.

http://www.pbase.com/liquidstone/image/134000218/original.jpg





Sep 26, 2017 at 12:26 AM
dehowie
Offline
• • •
Upload & Sell: Off
p.1 #8 · Imaging the ISS


https://photos.smugmug.com/Photography-around-the-Globe/The-Moon/i-6GB7j98/0/fc5238aa/O/IMG_5195.jpg

5Dsr and 600/4 with 2xTC.




Sep 26, 2017 at 07:25 AM
scott f
Offline
• • •
Upload & Sell: Off
p.1 #9 · Imaging the ISS


Is there a website that can tell you when it passes overhead of your location? Or, better yet, one that will tell you when it transits the moon?


Sep 26, 2017 at 08:35 AM
Mikehit
Offline
• • •
Upload & Sell: Off
p.1 #10 · Imaging the ISS


scott f wrote:
Is there a website that can tell you when it passes overhead of your location? Or, better yet, one that will tell you when it transits the moon?


If you google 'Tracking ISS' there are sites and smartphone apps that tell you when it flies over your location and where to look in the sky

Here is one:

https://spotthestation.nasa.gov/sightings/

https://www.nasa.gov/connect/apps.html




Sep 26, 2017 at 09:29 AM
hotdog12
Offline
• • •
Upload & Sell: Off
p.1 #11 · Imaging the ISS


The ISS (when it isn't in the Earth's shadow) is in direct sunlight. Expose accordingly at infinity. Lens? All you can get.

It appears as a very high fast-moving passenger jet until you use binoculars or start strapping on some long glass.

Lots of free apps out there to track its next appearance in your area.

A tripod or monopod is handy just for supporting the heavy lens you need to get a good shot, otherwise you can just track by hand.



Sep 26, 2017 at 10:45 AM
cameron12x
Offline
• • • •
Upload & Sell: On
p.1 #12 · Imaging the ISS


I don't know if these are my best images from tonight, but here goes. Taken with the same lens and body for perspective:

Image #1 Montage of Moon and ISS (cropped).
Image #2 Montage of Moon and ISS (cropped further).
Image #3 Enlarged version of ISS.

Canon 7D2, Canon 400mm F5.6L, Canon 1.4x TC II.

EDIT: EXIF metadata incorrect for the ISS image. Corrected: ISO 1600, f/8, 1/2000th.

For a sense of perspective, the ISS is about 240 miles away and the moon about 240,000 miles away.
















Edited on Sep 27, 2017 at 11:31 PM · View previous versions



Sep 26, 2017 at 10:06 PM
rsartin
Offline
• •
Upload & Sell: Off
p.1 #13 · Imaging the ISS


I've been trying this on and off for several months and still haven't gotten anything that wows me. I think one of my issues is too slow of a shutter speed when it is close to directly overhead. Next time it's around I am going to give it a shot at 1000mm on a 1.5 crop and be more mindful of my shutter speed.


Sep 27, 2017 at 07:53 PM
racoll
Offline
• • • •
Upload & Sell: On
p.1 #14 · Imaging the ISS


Very cool shots, everyone!

Andy



Sep 27, 2017 at 09:35 PM
Herb
Offline
• • • •
Upload & Sell: On
p.1 #15 · Imaging the ISS


Impressive...I think I saw that ISS once overhead and it was really moving in the sky...if that is what I saw, I am really impressed as that sucker was moving across the night skies.....


Sep 27, 2017 at 09:51 PM
gkowen
Offline

Upload & Sell: Off
p.1 #16 · Imaging the ISS


Impressive work! I have tried the last 3-4 nights to get a good photo of the ISS and failed. I have tried hand held, and tripod. Is there a lot of post processing on these images? Tonight I went out and took some hand held moon shots and they are perfectly clear and crisp. I am using a Canon 80D with a 100-400mm L lense and a 1.4 teleconverter. Here is a 300% blowup of what I get. I need to figurebula out uploading. It looks more like the Orion nebula. There is a lunar ISS transit tomorrow and 2 solar transits next month I am trying to get ready for. Thanks for all the help you have given here. Nice work!



Sep 29, 2017 at 10:46 PM
