First Shots with the Otus - Bokeh Samples


BA-photos
Offline
• •
Upload & Sell: On
p.2 #1 · First Shots with the Otus - Bokeh Samples


RCicala wrote:
I just got done running it through Imatest and it definitely is the new champion. Resolution is amazing. As expectied, of course.


Hi Roger, did you post your results yet? I checked but could not find it.



Nov 15, 2013 at 07:40 PM
RCicala
Offline
• • • •
Upload & Sell: On
p.2 #2 · First Shots with the Otus - Bokeh Samples


No, I just got the raw data this morning. I'll write it up over the weekend and have it posted Monday with any luck at all. If the weather holds I'll try to do some 55 Otus and 58mm Nikon comparison shots over the weekend, too.

Here's a bit of something, Imatest MTF50 numbers center, average of the lens, and corner. These are each a single lens shot, I haven't gotten all the data tabulated and averaged, but they seem representative.

All at f/1.4

Nikon 58mm f/1.4 on D3x 645 / 520 / 435
Nikon 58mm f/1.4 on D800e 700 / 540 / 475
Zeis Otus on D800e 945 / 785 / 670

The Zeiss numbers at f/1.4 are competitive with what I see from really good lenses at f/2.8 or f/4. I've never seen any lens do this at f/1.4.

Distortion is a very nice 0.8%, if there is field curvature, I can't detect it. Tests on the optical bench at infinity were just as good.




Nov 15, 2013 at 07:56 PM
snapsy
Offline
• • • •
Upload & Sell: On
p.2 #3 · First Shots with the Otus - Bokeh Samples


RCicala wrote:
All at f/1.4

Nikon 58mm f/1.4 on D3x 645 / 520 / 435
Nikon 58mm f/1.4 on D800e 700 / 540 / 475
Zeis Otus on D800e 945 / 785 / 670

The Zeiss numbers at f/1.4 are competitive with what I see from really good lenses at f/2.8 or f/4. I've never seen any lens do this at f/1.4.


Thanks Roger. Do you have any comparable numbers for the Sigma 35mm on a D800E? The Sigma article I found from you was when it first became available on a Canon mount.



Nov 15, 2013 at 08:14 PM
carstenw
Offline
• • • • • •
Upload & Sell: Off
p.2 #4 · First Shots with the Otus - Bokeh Samples


RCicala wrote:
All at f/1.4

Nikon 58mm f/1.4 on D3x 645 / 520 / 435
Nikon 58mm f/1.4 on D800e 700 / 540 / 475
Zeis Otus on D800e 945 / 785 / 670


Could you talk a bit about these numbers, and how they will compare in large prints and such? I am not really good at interpreting numbers like this.

How do results compare visually? I mean, if you have shots of anything other than test charts, how would you describe the boke from these two lenses? I am considering making one of these lenses a replacement for a bunch of lenses I don't use much, but I am not sure which. Normally I would just go for the Zeiss, but this Nikkor has me intrigued. I would be especially interested in shots at distances of 3-5m with the background at 8-15m, sort of full-body portraits or cars, with somewhat separate, but urban background.



Nov 15, 2013 at 08:57 PM
Jorge Torralba
Offline
• • • •
Upload & Sell: On
p.2 #5 · First Shots with the Otus - Bokeh Samples


Some more stuff. Used light room and applied "Direct Positive" to most of these for that snappy look.

You can follow other uploads here: http://zeissimages.com/standardgallery.php?lenstype=566&showall

































Nov 15, 2013 at 09:06 PM
RCicala
Offline
• • • •
Upload & Sell: On
p.2 #6 · First Shots with the Otus - Bokeh Samples


snapsy wrote:
Thanks Roger. Do you have any comparable numbers for the Sigma 35mm on a D800E? The Sigma article I found from you was when it first became available on a Canon mount.


Off the cuff (I'm out of the lab now) the Sigma was nearly 900 in the center, but more like 550 in the corners. It was the best until the Otus.



Nov 15, 2013 at 09:30 PM
RCicala
Offline
• • • •
Upload & Sell: On
p.2 #7 · First Shots with the Otus - Bokeh Samples


Carsten, probably the best visual comparison would be to convert the MTF numbers to SQF, like Pop Photo used to use.

This is a pretty big resolution difference - depending on which MTF (from 10 to 60) the difference ranges from 8 to 10. A difference of 5 is considered clearly visible in an 8 X 10 print.

That's really a huge difference. Usually when I say a better, it would take a 16 X 20 print (or equivalent cropping, etc.) to clearly see the difference.

To try to give some idea of the difference, the Sigma 35mm f/1.4 that I rave about is not quite 3 SQF points higher (on average) than the Canon 35mm f/1.4 (both excellent lenses, of course). The Canon 24-70 f/2.8 II at 70mm was about 4 SQF points higher than the original version.



Nov 15, 2013 at 09:44 PM
philip_pj
Offline
• • • •
Upload & Sell: Off
p.2 #8 · First Shots with the Otus - Bokeh Samples


'All at f/1.4

Nikon 58mm f/1.4 on D3x 645 / 520 / 435
Nikon 58mm f/1.4 on D800e 700 / 540 / 475
Zeis Otus on D800e 945 / 785 / 670'

Well, wow. Otus stronger/around equal corners than the Nikon centre...same camera. Nice illustration of sensor input also. Line up the FE 55mm please...



Nov 15, 2013 at 10:07 PM
snapsy
Offline
• • • •
Upload & Sell: On
p.2 #9 · First Shots with the Otus - Bokeh Samples


RCicala wrote:
Off the cuff (I'm out of the lab now) the Sigma was nearly 900 in the center, but more like 550 in the corners. It was the best until the Otus.


Great, thanks. Sounds like the Sigma is at least in the same universe as the Otus. Oh man I hope Sigma does a 50mm ART.



Nov 15, 2013 at 10:20 PM
MaxBerlin
Offline
• • •
Upload & Sell: Off
p.2 #10 · First Shots with the Otus - Bokeh Samples


Roger - what about the 135 APO ? Where does it line up with these ?


Nov 15, 2013 at 10:33 PM


Search in Used Dept.



Jorge Torralba
Offline
• • • •
Upload & Sell: On
p.2 #11 · First Shots with the Otus - Bokeh Samples


The APO 135 is amazing. Out of this world. My favorite lineup as it stands now is the 25 f2, 135 f2 and the 55 1.4

Here are some from the 135

http://zeissimages.com/standardgallery.php?lenstype=557&showall








Nov 15, 2013 at 10:39 PM
sflxn
Offline
• • •
Upload & Sell: On
p.2 #12 · First Shots with the Otus - Bokeh Samples


The 135 APO numbers are on lensrental's site.

http://www.lensrentals.com/blog/2013/04/zeiss-ze-135mm-f2-vs-canon-135mm-f2l

It's tested on a Canon 5DIII. Quite extraordinary lenses coming out of Zeiss and Sigma these days.



Nov 15, 2013 at 10:41 PM
theSuede
Offline
• • • •
Upload & Sell: Off
p.2 #13 · First Shots with the Otus - Bokeh Samples


carstenw wrote:
Could you talk a bit about these numbers, and how they will compare in large prints and such? I am not really good at interpreting numbers like this.

How do results compare visually? I mean, if you have shots of anything other than test charts, how would you describe the boke from these two lenses? I am considering making one of these lenses a replacement for a bunch of lenses I don't use much, but I am not sure which. Normally I would just go for the Zeiss, but this Nikkor has me intrigued. I would be especially interested in shots
...Show more

That's REALLY hard to tell... If you're comparing lenses that are somewhat similar in general rendering and "other" qualities, the numbers are accurate down to a certain degree. And certainly after the lens(es) have been stopped down by a full step.

At least with large-aperture lenses like the F1.4's, Imatest did at least USE to show very inflated numbers for lenses with low global contrast, wide open. So for lenses like the Canon/Nikon/Zeiss 50/1.4's, the F1.4 MTF50 values were much higher than what they "should" have been. That took me a while to catch on to, and to get some kind of analytical explanation for.

In Imatest master, I think you can now insert the "veiling flare" MTF baseline into the SFR measurement. This sets the "starting point" for the MTF - low frequencies like 2-5 lp/mm - lower. Then the lens will also reach the set MTF70/50/30 cutoff points earlier.

In some older lenses I found a 15% increase in Imatest indicated MTF50 compared to a real traversing slit measurement, wide open. That was lowered to a few percent (or nothing) after one or two stops down.

This will also upset quite a lot of people with lenses like the new Nikon 58. The MTF numbers extracted by software suits like Imatest or the simpler DxO packages just will not show the "correct" difference towards the more normal 50mm lenses. Weighing systems like the DxO "perceptual MP" - which I don't like for other reasons - or the SQF series in imatest - that include the baseline contrast compensation - will show other differences.

You really have to have both together (or alternatively, a real bench measured MTF!) to get the "whole picture".



Nov 15, 2013 at 10:44 PM
pookipichu
Offline
• • •
Upload & Sell: Off
p.2 #14 · First Shots with the Otus - Bokeh Samples


Shot through glass window. The rendering of this lens is spectacular. Color separation, resolution, micro contrast. It's absolutely superb and a tremendous tool for capturing light. By far the sharpest lens at 1.4 of any I have tried.

Nikon D800
Exposure1/3200 sec
Aperturef/1.4
Focal Length55 mm
ISO Speed100






Nov 15, 2013 at 11:24 PM
agprkr
Offline

Upload & Sell: On
p.2 #15 · First Shots with the Otus - Bokeh Samples


Received my OTUS on Wednesday. Here is one of my first shots taken during the afternoon. This was shot hand-held at f/1.4. I really like the design and build of the lens although it is heavy.








Nov 16, 2013 at 03:02 PM
bushwacker
Offline
• • •
Upload & Sell: Off
p.2 #16 · First Shots with the Otus - Bokeh Samples


Jorge Torralba wrote:
Some more stuff. Used light room and applied "Direct Positive" to most of these for that snappy look.

You can follow other uploads here: http://zeissimages.com/standardgallery.php?lenstype=566&showall



Hey Jorge,

I noticed something on this lens, the sample shots [ you have ] has the sharpness in them now when compared to other non-zeiss lenses they are sharp too but gritty sharp or say clinically sharp then your eyes will start to irritate or wander around across the frame looking for something.

with your shots it's dead on the spot what are you trying to convey and it's pleasing to the eye. I don't know how to say it, the pics are clean and sharp but they're not gritty sharp like most non- zeiss do.



Nov 16, 2013 at 04:50 PM
bushwacker
Offline
• • •
Upload & Sell: Off
p.2 #17 · First Shots with the Otus - Bokeh Samples


agprkr wrote:
Received my OTUS on Wednesday. Here is one of my first shots taken during the afternoon. This was shot hand-held at f/1.4. I really like the design and build of the lens although it is heavy.



Jorge and Agprkr:

Will it be okay for you to post a pic with a subject-distance of 2.5 meters with 7 to 15 meter background at these apertures: f/1.4, f2, f/2.8 and f/4





Nov 16, 2013 at 04:56 PM
wayne seltzer
Offline
• • • •
Upload & Sell: Off
p.2 #18 · First Shots with the Otus - Bokeh Samples


The Lenstip review has plenty bokeh samples at different apertures. Have you looked at them? The model with b&w checkered jacket and same background is a good torture test for bokeh and the Otus handled it well.

http://www.lenstip.com/2067-news-Zeiss_Otus_55_mm_f_1.4_-_sample_images.html



Nov 16, 2013 at 05:15 PM
Jorge Torralba
Offline
• • • •
Upload & Sell: On
p.2 #19 · First Shots with the Otus - Bokeh Samples


bushwacker wrote:
Jorge and Agprkr:

Will it be okay for you to post a pic with a subject-distance of 2.5 meters with 7 to 15 meter background at these apertures: f/1.4, f2, f/2.8 and f/4



I will try and get something later today if it stops raining. But here is something with those approximate distances. Exif data can be seen HERE








Nov 16, 2013 at 06:21 PM
hiepphotog
Online
• • •
Upload & Sell: On
p.2 #20 · First Shots with the Otus - Bokeh Samples


Thank you Jorge. I am not sure about King of Bokeh, but certainly it's the King of Sharpness for a 50 to me.

Can you take a picture of the rear mount? I want to see if my Leitax mount would fit the ZF version. Much appreciated.



Nov 16, 2013 at 06:26 PM
