DavidBM wrote:
I then moved the focus point left to the mid-zone and then as close to the left edge as possible, making another three exposures each time. Since, at each of these locations, the sharpest focus was also at the hard stop, there is no point showing images to demonstrate subtle changes in focus since there were none.
What I've done instead is shown the results for the three different apertures to illustrate how the resulting images sharpen as the lens is stopped down. I hope this is useful.
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-full-frame-900.jpg
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-composite.jpgImpressive!
The edge, though, is still midfield (the corner of course gives the outer field). While it doesn’t matter in practice, it might be our fir the pixel peepers to know if FC shows up in the corners..
That's the first thing I noticed David. However, on the Sony, there is very noticeable curvature at mid-field and therefore his test shows there is induced field curvature when combining this lens with a thicker sensor stack. Basically his edge crop was my mid-field crop.
@genji mentioned to me that the lens' focusing ring was always at the hard stop regardless of where he focus at infinity. On the Sony, that only happens at mid field. Center and extreme edges perform better a tad before the infinity hard stop.
Having said that, field curvature gets pretty much masked at f/4-5.6 making it still a great choice for landscapes on the Sony. Personally I see it as a general, candid/portraits lens so field curvature is not as relevant even wide open.
genji wrote
As I mentioned in a previous post, I tested my copy of the CV 75/1.5 on an infinity scene with my Leica M10-P and found it has essentially a flat field. Using the Leica Visoflex 020 external EVF, I focused on the center of the scene (which was at the hard infinity stop) and took exposures at f/1.5, f2.0, and f/2.8.I then moved the focus point left to the mid-zone and then as close to the left edge as possible, making another three exposures each time. Since, at each of these locations, the sharpest focus was also at the hard stop, there is no point showing images to demonstrate subtle changes in focus since there were none.
What I've done instead is shown the results for the three different apertures to illustrate how the resulting images sharpen as the lens is stopped down. I hope this is useful.
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-full-frame-900.jpg
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-composite.jpg
The edge, though, is still midfield (the corner of course gives the outer field). While it doesn’t matter in practice, it might be our fir the pixel peepers to know if FC shows up in the corners..
That's the first thing I noticed David. However, on the Sony, there is very noticeable curvature at mid-field and therefore his test shows there is induced field curvature when combining this lens with a thicker sensor stack. Basically his edge crop was my mid-field crop.
@genji mentioned to me that the lens' focusing ring was always at the hard stop regardless of where he focus at infinity. On the Sony, that only happens at mid field. Center and extreme edges perform better a tad before the infinity hard stop.
Having said that, field curvature gets pretty much masked at f/4-5.6 making it still a great choice for landscapes on the Sony. Personally I see it as a general, candid/portraits lens so field curvature is not as relevant even wide open.
Aug 14, 2019 at 10:33 AM
p.4 #2Voigtlander 75mm f/1.5 Nokton Review
GMPhotography wrote:
I'm shooting Big Bronco right now. No difference in focus from center to extreme corner. Ziltch
On the Sony those are in the same plane. The mid-field is the area with curvature and @genji's test indicates the lens is not optimized for the Sony's thicker sensor stack.
I'm shooting Big Bronco right now. No difference in focus from center to extreme corner. Ziltch
On the Sony those are in the same plane. The mid-field is the area with curvature and @genji's test indicates the lens is not optimized for the Sony's thicker sensor stack.
Aug 14, 2019 at 10:41 AM
p.4 #3Voigtlander 75mm f/1.5 Nokton Review
GMPhotography wrote:
I should have said a modern Lux. Yes it's sharper and better corrected in my mind though it's the immediate falloff from sharp to OOF which reminds me of a Lux
Ahh, yes. This makes more sense. As a much more modern interpretation I get you.
I should have said a modern Lux. Yes it's sharper and better corrected in my mind though it's the immediate falloff from sharp to OOF which reminds me of a Lux
Ahh, yes. This makes more sense. As a much more modern interpretation I get you.
Aug 14, 2019 at 11:01 AM
p.4 #4Voigtlander 75mm f/1.5 Nokton Review
Fred Miranda wrote:
I then moved the focus point left to the mid-zone and then as close to the left edge as possible, making another three exposures each time. Since, at each of these locations, the sharpest focus was also at the hard stop, there is no point showing images to demonstrate subtle changes in focus since there were none.
What I've done instead is shown the results for the three different apertures to illustrate how the resulting images sharpen as the lens is stopped down. I hope this is useful.
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-full-frame-900.jpg
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-composite.jpgImpressive!
The edge, though, is still midfield (the corner of course gives the outer field). While it doesn’t matter in practice, it might be our fir the pixel peepers to know if FC shows up in the corners..That's the first thing I noticed David. However, on the Sony, there is very noticeable curvature at mid-field and therefore his test shows there is induced field curvature when combining this lens with a thicker sensor stack. Basically his edge crop was my mid-field crop.
@genji@ mentioned to me that the lens' focusing ring was always at the hard stop regardless of where he focus at infinity. On the Sony, that only happens at mid field. Center and extreme edges perform better a tad before the infinity hard stop.
Having said that, field curvature gets pretty much masked at f/4-5.6 making...Show more →
Comparing your shots to Jonathon's (genji's) shots, I very slightly prefer the shots with the Leica. In addition to the induced field curvature it looks like there is just a bit of induced astigmatism (probably more induction of field curvature in one plane than the other) toward the corners. Still I think on Sony the performance is excellent stopped down to f/5.6 and very very good stopped down to f/4. It just seems to me a little better on the Leica. Of course they are not side by side tests and the lighting is different, etc., so I could be wrong. Still I would love to see an FE version of this lens that I think on Sony would be just a small bit better.
DavidBM wrote
genji wrote
As I mentioned in a previous post, I tested my copy of the CV 75/1.5 on an infinity scene with my Leica M10-P and found it has essentially a flat field. Using the Leica Visoflex 020 external EVF, I focused on the center of the scene (which was at the hard infinity stop) and took exposures at f/1.5, f2.0, and f/2.8.I then moved the focus point left to the mid-zone and then as close to the left edge as possible, making another three exposures each time. Since, at each of these locations, the sharpest focus was also at the hard stop, there is no point showing images to demonstrate subtle changes in focus since there were none.
What I've done instead is shown the results for the three different apertures to illustrate how the resulting images sharpen as the lens is stopped down. I hope this is useful.
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-full-frame-900.jpg
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-composite.jpg
The edge, though, is still midfield (the corner of course gives the outer field). While it doesn’t matter in practice, it might be our fir the pixel peepers to know if FC shows up in the corners..
@genji@ mentioned to me that the lens' focusing ring was always at the hard stop regardless of where he focus at infinity. On the Sony, that only happens at mid field. Center and extreme edges perform better a tad before the infinity hard stop.
Having said that, field curvature gets pretty much masked at f/4-5.6 making...Show more →
Comparing your shots to Jonathon's (genji's) shots, I very slightly prefer the shots with the Leica. In addition to the induced field curvature it looks like there is just a bit of induced astigmatism (probably more induction of field curvature in one plane than the other) toward the corners. Still I think on Sony the performance is excellent stopped down to f/5.6 and very very good stopped down to f/4. It just seems to me a little better on the Leica. Of course they are not side by side tests and the lighting is different, etc., so I could be wrong. Still I would love to see an FE version of this lens that I think on Sony would be just a small bit better.
Aug 14, 2019 at 11:47 AM
p.4 #5Voigtlander 75mm f/1.5 Nokton Review
Steve Spencer wrote:
I then moved the focus point left to the mid-zone and then as close to the left edge as possible, making another three exposures each time. Since, at each of these locations, the sharpest focus was also at the hard stop, there is no point showing images to demonstrate subtle changes in focus since there were none.
What I've done instead is shown the results for the three different apertures to illustrate how the resulting images sharpen as the lens is stopped down. I hope this is useful.
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-full-frame-900.jpg
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-composite.jpgImpressive!
The edge, though, is still midfield (the corner of course gives the outer field). While it doesn’t matter in practice, it might be our fir the pixel peepers to know if FC shows up in the corners..That's the first thing I noticed David. However, on the Sony, there is very noticeable curvature at mid-field and therefore his test shows there is induced field curvature when combining this lens with a thicker sensor stack. Basically his edge crop was my mid-field crop.
@genji@@ mentioned to me that the lens' focusing ring was always at the hard stop regardless of where he focus at infinity. On the Sony, that only happens at mid field. Center and extreme edges perform better a tad before the infinity hard stop.
Having said that, field curvature gets pretty much masked at f/4-5.6 making it still a great choice for landscapes on the Sony. Personally I see it as a general, candid/portraits lens so field curvature is not as relevant even wide open.Comparing your shots to Jonathon's (genji's) shots, I very slightly prefer the shots with the Leica. In addition to the induced field curvature it looks like there is just a bit of induced astigmatism (probably more induction of field curvature in one plane than the other) toward the corners. Still I think on Sony the performance is excellent stopped down to f/5.6 and very very good stopped down to f/4. It just seems to me a little better on the Leica. Of course they are not side by side tests and the lighting is different, etc., so I could...Show more →
Same here Steve. Field curvature also affects bokeh rendering but I don't see any rendering weirdness even when shooting wide open on the Sony. For anything else aside from landscapes at wide apertures, the M-mount should perform just as good on the Sony.
For a dedicated landscape lens, perhaps a future E-mount version would be preferred but it's not guaranteed Voigtlander will produce one.
Fred Miranda wrote
DavidBM wrote
genji wrote
As I mentioned in a previous post, I tested my copy of the CV 75/1.5 on an infinity scene with my Leica M10-P and found it has essentially a flat field. Using the Leica Visoflex 020 external EVF, I focused on the center of the scene (which was at the hard infinity stop) and took exposures at f/1.5, f2.0, and f/2.8.I then moved the focus point left to the mid-zone and then as close to the left edge as possible, making another three exposures each time. Since, at each of these locations, the sharpest focus was also at the hard stop, there is no point showing images to demonstrate subtle changes in focus since there were none.
What I've done instead is shown the results for the three different apertures to illustrate how the resulting images sharpen as the lens is stopped down. I hope this is useful.
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-full-frame-900.jpg
http://d1u92k3d1w68j5.cloudfront.net/lens-tests/cv-7515-composite.jpg
The edge, though, is still midfield (the corner of course gives the outer field). While it doesn’t matter in practice, it might be our fir the pixel peepers to know if FC shows up in the corners..
@genji@@ mentioned to me that the lens' focusing ring was always at the hard stop regardless of where he focus at infinity. On the Sony, that only happens at mid field. Center and extreme edges perform better a tad before the infinity hard stop.
Having said that, field curvature gets pretty much masked at f/4-5.6 making it still a great choice for landscapes on the Sony. Personally I see it as a general, candid/portraits lens so field curvature is not as relevant even wide open.
Same here Steve. Field curvature also affects bokeh rendering but I don't see any rendering weirdness even when shooting wide open on the Sony. For anything else aside from landscapes at wide apertures, the M-mount should perform just as good on the Sony.
For a dedicated landscape lens, perhaps a future E-mount version would be preferred but it's not guaranteed Voigtlander will produce one.
Aug 14, 2019 at 12:09 PM
p.4 #6Voigtlander 75mm f/1.5 Nokton Review
thanks @genji for the test. Seems like it performs quite a bit better on your M.
I tested a bit more and just updated my rolling review. One interesting finding is that the Voigtlander is pretty soft at the close focusing distance. Here the Sony FE 1.8/85 smokes it:
At a focus distance of a little over 2m sharpness improves a lot: https://phillipreeve.net/blog/wp-content/uploads/2019/08/sharpness_portrait_f14.jpg
That also explains why I was less happy with my (mostly tight) portraits while Fred was happier with his. I think this might be a little exaggerated by the thicker stack but it is mostly a result of it being a block focusing lens while the FE 1.8/85 at least has a fixed group.
Personally I like the lens quite a bit and I might be tempted to get one if there is ever an E-mount version but there are a few downsides too many with the adapted M-mount version for me to buy one now.
I tested a bit more and just updated my rolling review. One interesting finding is that the Voigtlander is pretty soft at the close focusing distance. Here the Sony FE 1.8/85 smokes it:
At a focus distance of a little over 2m sharpness improves a lot: https://phillipreeve.net/blog/wp-content/uploads/2019/08/sharpness_portrait_f14.jpg
That also explains why I was less happy with my (mostly tight) portraits while Fred was happier with his. I think this might be a little exaggerated by the thicker stack but it is mostly a result of it being a block focusing lens while the FE 1.8/85 at least has a fixed group.
Personally I like the lens quite a bit and I might be tempted to get one if there is ever an E-mount version but there are a few downsides too many with the adapted M-mount version for me to buy one now.
Aug 14, 2019 at 02:24 PM
p.4 #9Voigtlander 75mm f/1.5 Nokton Review
Center Test Big Bronco Side wall
Full Frame
1.5
F2
F2.8
Full Frame
1.5
F2
F2.8
Aug 14, 2019 at 04:43 PM
p.4 #10Voigtlander 75mm f/1.5 Nokton Review
As you can see 1.5 is very nice but a big jump at F2. I honestly like that as at 1.5 I can use for softer looks. My ideal a lens that has two looks
Edited on Aug 14, 2019 at 05:02 PM · View previous versions
Edited on Aug 14, 2019 at 05:02 PM · View previous versions
Aug 14, 2019 at 04:48 PM
|
p.4 #11Voigtlander 75mm f/1.5 Nokton Review
CA goes away naturally at 2.8. Let me process Big Bronco on that
Aug 14, 2019 at 04:49 PM
p.4 #12Voigtlander 75mm f/1.5 Nokton Review
Big Bronco at F2.8 just looking at the distortion which looks very minimal. Not a perfect building though but a little pin cushion
Aug 14, 2019 at 04:52 PM
p.4 #13Voigtlander 75mm f/1.5 Nokton Review
Okay metal straps at 2.8 the CA goes away on its on.
1.5
F2
F2.8
1.5
F2
F2.8
Aug 14, 2019 at 04:55 PM
p.4 #15Voigtlander 75mm f/1.5 Nokton Review
Watch the Bokeh Balls here as they change with aperture. Im handheld so little movement on my part as I'm squatting down too
1.5
F2
F2.8
F4
F5.6
1.5
F2
F2.8
F4
F5.6
Aug 14, 2019 at 05:01 PM
p.4 #16Voigtlander 75mm f/1.5 Nokton Review
Interesting F4 looks round and no mechanical vignette
I have more so look at that again
I have more so look at that again
Aug 14, 2019 at 05:06 PM
p.4 #18Voigtlander 75mm f/1.5 Nokton Review
Another series of apertures
1.5
F2
F2.8
F4
F5.6
1.5
F2
F2.8
F4
F5.6
Aug 14, 2019 at 05:13 PM
p.4 #20Voigtlander 75mm f/1.5 Nokton Review
Okay I'm outta here to celebrate my health news. Hope these help a little
I'm really liking this. Glad I got it
I'm really liking this. Glad I got it
