Adapting Lenses to the Fuji GFX



baumgarten0712
Online
• • •
Upload & Sell: On
p.104 #1 · p.104 #1 · Adapting Lenses to the Fuji GFX


500 PF + 1.4x + 100 II + Sparrow....pretty sharp combo!




  GFX100 II    NIKON AF-S NIKKOR 500mm f/5.6E PF ED VR + 1.4X lens    700mm    f/9.0    1/640s    6400 ISO    -1.3 EV




Dec 11, 2023 at 09:26 PM
KENNNN
Offline

Upload & Sell: Off
p.104 #2 · p.104 #2 · Adapting Lenses to the Fuji GFX


A China local brand (brand name: OPT) industrial line scan lens 40mm/4.5, designed image circle 63mm, recommended magnigication is 0.01-0.26X.
















Dec 12, 2023 at 03:32 AM
leonasj
Offline
• • •
[X]
p.104 #3 · p.104 #3 · Adapting Lenses to the Fuji GFX


jpeg, wide open .



© leonasj 2023

  GFX100S    MC ZENITAR-M2s 2/50 lens    50mm    f/0.0    1/40s    800 ISO    0.0 EV




Jan 04, 2024 at 11:36 AM
hubsand
Offline
• • • •
Upload & Sell: Off
p.104 #4 · p.104 #4 · Adapting Lenses to the Fuji GFX


AZSteve wrote:
I do wish people when referring to corner coverage would be careful to elaborate. One can imagine illumination of the corner with minimal definition, suitable for OOF foreground and sky but not detail in focus, and illumination (or partial illumination, corrigible in post) with good definition.


Yes. And yes.

So, a better way to refer to this, and 'sides' and 'corners' in general, is to divide the general image circle into concentric rings - Zones A to D. These correspond to vertical stripes on MTF charts. For more on that, please see here: Fuji GFX Adapted Lenses

Also, discussions involving the GFX have revealed the need for a more precise definition of 'coverage'. Perhaps the clearest definition of coverage would involve the absence of a 'hard' (whatever that means) vignette caused by a mechanical obstruction. Where a soft vignette begins and ends is - literally - a grey area.

As has been pointed out, if we apply too strict a definition, many native lenses would not qualify as 'covering' their own format. A particularly heinous example of this is the Sony 18-135mm which at 18mm is completely inadequate for APS-C.

I think we have to regard illumination as the fundamental, but aberration as a distinct, secondary property. White wall tests effectively show whether a lens 'covers' GFX, but it doesn't quantify deleterious aberrations in Zone D. It's also true (noted earlier) that vignetting inconsistently differs with focal length and aperture.

To give an example: wide open, it appears that both the Sigma 50mm Art and Tamron SP 45mm cover GFX with only a soft vignette. The Sigma throws a better illuminated image circle at f1.4 than the Tamron does at f1.8. However, only when stopping both down and observing their different behaviour in Zone D do we see that the Tamron reaches a peak of performance at f8-f11 in which aberrations are largely absent. Whereas stepping through the full range of apertures with the Sigma Art, it is shown in extremis that its image circle is actually smaller, inasmuch as its Zone D is never aberration-free.

Edited on Jan 25, 2024 at 04:23 PM · View previous versions



Jan 25, 2024 at 04:13 PM
hubsand
Offline
• • • •
Upload & Sell: Off
p.104 #5 · p.104 #5 · Adapting Lenses to the Fuji GFX


KENNNN wrote:
As an amateur photo enthusiast, I have been struggling in getting better cameras and lenses within budget for many years. Fortunately to me, this money-burning and time-consuming practice has somehow satisfied my exploring curiosity as a technical man and improved my photography skills. I believe many people in this forum have the same situation like me.

Like many others, at the beginning, I tried to adapt different types of 3rd party lenses to GFX since I got a second-handed 50s last year. Recently I switched to a new 100S, I of course will continue to do so. My practice involved 35mm
...Show more

A fellow traveller! Welcome . . .

The only reason I have a GFX is to give an optimal outlet to my collection of enlarger, projector and industrial lenses. I'm gradually compiling vignette maps at the page linked above: they may be of interest to you - Fuji GFX Adapted Lenses.

It seems that if we put our heads together we could greatly enlarge the range of lenses covered. I'll PM you.

Recently I made a close comparison of the Schneider Apo-Componon 60/4 with the Nikon EL-Nikkor 63/2.8 and found the Nikon even better suited to general use, and fully covered GFX. But there are hundreds of these lenses that work brilliantly on the GFX. See also Delta Lenses



Jan 25, 2024 at 04:19 PM
lifeandmylens
Offline
• • •
Upload & Sell: On
p.104 #6 · p.104 #6 · Adapting Lenses to the Fuji GFX


Can anyone recommend a way to use Contax G lenses on the GFX?


Feb 24, 2024 at 11:37 AM
helimat
Offline
• • • • •
Upload & Sell: On
p.104 #7 · p.104 #7 · Adapting Lenses to the Fuji GFX


lifeandmylens wrote:
Can anyone recommend a way to use Contax G lenses on the GFX?


Maybe by first converting to M mount a 'la Funleader Kit or similar? I would have to think they would suffer from heavy vignetting and/or corner smearing on the larger sensor however.

50S II + Minolta MD 100/2.5







Feb 26, 2024 at 11:24 AM
markhout
Offline
• • •
Upload & Sell: Off
p.104 #8 · p.104 #8 · Adapting Lenses to the Fuji GFX


Helios time! Of both the Helios 40-2 and 44-2 I appreciate the center sharpness - and the unsharp / bokeh areas even more.

(click on the image if it doesn't fit your screen)

50S II + Helios 40-2 (85mm 1.5 wide open) + extension ring (cropped slightly to 4x5)




50S II + Helios 44-2 (58mm 2.0 wide open) (uncropped)







Mar 02, 2024 at 10:35 AM
helimat
Offline
• • • • •
Upload & Sell: On
p.104 #9 · p.104 #9 · Adapting Lenses to the Fuji GFX


50S II + Pentax 31/1.8







Mar 02, 2024 at 01:15 PM
markhout
Offline
• • •
Upload & Sell: Off
p.104 #10 · p.104 #10 · Adapting Lenses to the Fuji GFX


50S II + Nikon 20mm / 4.0 AI @ 11 in-camera pano crop

vignetting uncorrected

(click on the image if it doesn't fit your screen)





Mar 03, 2024 at 08:34 AM



Search in Used Dept.

helimat
Offline
• • • • •
Upload & Sell: On
p.104 #11 · p.104 #11 · Adapting Lenses to the Fuji GFX


50S II + Minolta MD 100/2.5







Mar 11, 2024 at 10:07 PM
KENNNN
Offline

Upload & Sell: Off
p.104 #12 · p.104 #12 · Adapting Lenses to the Fuji GFX


Great vignette map test! nikon rayfact industrial linescan or its enlarger version 63/2.8 is an ideal prime lens for 4433 system. For 28mm legancy 35mm fullframe lens, the MD 28/2.8 is also very good.

hubsand wrote:
A fellow traveller! Welcome . . .

The only reason I have a GFX is to give an optimal outlet to my collection of enlarger, projector and industrial lenses. I'm gradually compiling vignette maps at the page linked above: they may be of interest to you - Fuji GFX Adapted Lenses.

It seems that if we put our heads together we could greatly enlarge the range of lenses covered. I'll PM you.

Recently I made a close comparison of the Schneider Apo-Componon 60/4 with the Nikon EL-Nikkor 63/2.8 and found the Nikon even better suited to general use, and fully covered GFX. But
...Show more



Mar 12, 2024 at 12:03 AM
KENNNN
Offline

Upload & Sell: Off
p.104 #13 · p.104 #13 · Adapting Lenses to the Fuji GFX


Minolta MD 28/2.8, no crop, no post-processing








Mar 14, 2024 at 01:45 AM
KENNNN
Offline

Upload & Sell: Off
p.104 #14 · p.104 #14 · Adapting Lenses to the Fuji GFX


Minolta MC 28/2, 6:7 crop mode

















Mar 14, 2024 at 02:07 AM
itsmrjack
Offline

Upload & Sell: Off
p.104 #15 · p.104 #15 · Adapting Lenses to the Fuji GFX


Hi, what adapter are you using to mount the El-Nikkor 63mm f2.8N enlarger lens?

I gather it is M39 mount. I have found two mounting options:

One that is almost flush with the camera - Fotodiox sell this https://fotodioxpro.com/products/l39-gfx-p

And one that appears to act as a focusing helicoid - found this on AliExpress https://fr.aliexpress.com/i/33050051836.html?gatewayAdapt=glo2fra

This leads me to wonder about the Nikkor lens itself - does it have both aperture and focus rings?

Sorry for the links, I wanted to post photos of the adapters but I'm too new on the forum I think.

hubsand wrote:
A fellow traveller! Welcome . . .

The only reason I have a GFX is to give an optimal outlet to my collection of enlarger, projector and industrial lenses. I'm gradually compiling vignette maps at the page linked above: they may be of interest to you - Fuji GFX Adapted Lenses.

It seems that if we put our heads together we could greatly enlarge the range of lenses covered. I'll PM you.

Recently I made a close comparison of the Schneider Apo-Componon 60/4 with the Nikon EL-Nikkor 63/2.8 and found the Nikon even better suited to general use, and fully covered GFX. But
...Show more



Mar 22, 2024 at 04:14 AM
markhout
Offline
• • •
Upload & Sell: Off
p.104 #16 · p.104 #16 · Adapting Lenses to the Fuji GFX


Interesting stuff. I have both the El-Nikkor N 50mm 2.8 and the 80mm 5.6. They both have M39 thread. No focus mechanism, so using these lenses on a GFX requires a helicoid adapter.

Thanks for that Aliexpress link. Browsing on Aliexpress it looks like there are various sizes helicoid adapters, to allow for infinity focus at various focal lengths. I will order the adapter for 80mm, assuming that the 50mm will focus beyond infinity on that adapter but that's ok for now.



Mar 22, 2024 at 07:48 AM
itsmrjack
Offline

Upload & Sell: Off
p.104 #17 · p.104 #17 · Adapting Lenses to the Fuji GFX



markhout wrote:
Thanks for that Aliexpress link. Browsing on Aliexpress it looks like there are various sizes helicoid adapters, to allow for infinity focus at various focal lengths. I will order the adapter for 80mm, assuming that the 50mm will focus beyond infinity on that adapter but that's ok for now.


Yeah random find but it seems these are made by Pixco and designed for specific lenses, ie. Rodenstock 80mm and 90mm f4 and Industar 75mm and 110mm f4 lenses.

https://pixco.com.cn/search?type=product&options%5Bprefix%5D=last&q=M39+gfx

I have emailed them to ask if they will make one for the El-Nikkor 63mm f2.8N! 🙏



Mar 22, 2024 at 09:06 AM
Picture This!
Offline
• • • •
Upload & Sell: On
p.104 #18 · p.104 #18 · Adapting Lenses to the Fuji GFX


Has anyone tried the Nikon 85mm 1.4 AF-S (or the older AF-D) with the gfx ? How does it fare ?


Mar 23, 2024 at 03:24 PM
markhout
Offline
• • •
Upload & Sell: Off
p.104 #19 · p.104 #19 · Adapting Lenses to the Fuji GFX


Hasselblad 150mm / 4 CF Sonnar at f8/11, tripod, 50S2, cropped to 4x5

(click on the image if it doesn't fit your screen)



Edited on Mar 24, 2024 at 07:13 AM · View previous versions



Mar 24, 2024 at 07:09 AM
markhout
Offline
• • •
Upload & Sell: Off
p.104 #20 · p.104 #20 · Adapting Lenses to the Fuji GFX


Picture This! wrote:
Has anyone tried the Nikon 85mm 1.4 AF-S (or the older AF-D) with the gfx ? How does it fare ?


Not sure if you're aware of this amazing resource:

https://docs.google.com/spreadsheets/d/1uxvvpxJ9QVFFyh0pW2rs9KBmUW9vlh-d-VnbcLDCTn8/edit#gid=0&range=B561

This is a good place to start.



Mar 24, 2024 at 07:12 AM
