p.1 #1 · Mola PAD (Perforated Aluminium Diffuser)

Can someone who has one of these diffusers for a Demi tell me approximately how large the holes are and how far apart they are spaced? I'm in the process of fabricating a DIY dish and I can't find any specs or measurements on this Mola accessory.

Thanks.

(edited to correct title)

Edited on Jun 27, 2012 at 08:30 AM · View previous versions

Jun 26, 2012 at 11:59 PM

Sheldon N
Offline
• • •
Upload & Sell: On

p.1 #2 · Mola PAD (Perforated Aluminium Diffuser)

No measurements handy, but here are some pics...

If I recall correctly, the diameter of the whole disc is about 8 inches.

This image is copyrighted by the owner

Jun 27, 2012 at 12:19 AM

Ho1972
Offline
• • •
Upload & Sell: On

p.1 #3 · Mola PAD (Perforated Aluminium Diffuser)

That's a pretty fine mesh. Judging from the way the holes run all the way out to the edges, it looks as if it is cut from standard perforated stock. Whether it is or not, I should at least be able to find something close.

Thanks.

PS: I'll still happily take measurements if anyone has them.

Jun 27, 2012 at 12:28 AM

Ho1972
Offline
• • •
Upload & Sell: On

p.1 #4 · Mola PAD (Perforated Aluminium Diffuser)

Since no measurements seem to be forthcoming, I ordered some perforated aluminum stock (12x12 piece). It has 3/32 (0.09375") dia holes and an open area of 33%. Kind of hard to tell from the photos how close this may be to Mola's material but it's what I'm going with for now.

Jun 29, 2012 at 09:47 PM

zurkzees
Offline
• •
Upload & Sell: Off

p.1 #5 · Mola PAD (Perforated Aluminium Diffuser)

Jul 01, 2012 at 11:25 PM

Ho1972
Offline
• • •
Upload & Sell: On

p.1 #6 · Mola PAD (Perforated Aluminium Diffuser)

Wow, thanks. Looks like the holes are closer to 1/16 than 3/32 though. I guess being 1/32 off isn't bad for guess work.

Jul 01, 2012 at 11:57 PM

Ho1972
Offline
• • •
Upload & Sell: On

p.1 #7 · Mola PAD (Perforated Aluminium Diffuser)

Thanks to Sheldon and especially Zurkzees for their "measured" responses to my question.

The beauty dish lives. Maybe someday I'll get to try it on a humanoid...

NIKON D200 40 mm f/9.0 1/125 sec 100 ISO 0.0 EV

Jul 14, 2012 at 09:07 PM

markd61
Offline
• •
Upload & Sell: On

p.1 #8 · Mola PAD (Perforated Aluminium Diffuser)

Beautiful shot.
Do you have a sample that shows the difference between diffuser and no diffuser?

Jul 14, 2012 at 09:47 PM

Ho1972
Offline
• • •
Upload & Sell: On

p.1 #9 · Mola PAD (Perforated Aluminium Diffuser)

markd61 wrote:
Beautiful shot.

Thanks.

Do you have a sample that shows the difference between diffuser and no diffuser?

Not one that I'd want to post, but I'll put it on my to do list. If I don't get to it tonight it will be sometime next week. I should point out that I used a 7 inch styrofoam plate in conjunction with the PAD for this shot. The plate is my substitute for Mola Opal glass...

Jul 14, 2012 at 09:50 PM

Sheldon N
Offline
• • •
Upload & Sell: On

p.1 #10 · Mola PAD (Perforated Aluminium Diffuser)

Nice shot! The Styrofoam plate certainly is less expensive than the Opal glass.

Jul 15, 2012 at 03:02 PM

Ho1972
Offline
• • •
Upload & Sell: On

p.1 #11 · Mola PAD (Perforated Aluminium Diffuser)

OK, here are the steps from no diffusion to full. For the no diffusion shot, I still left the snap on (Stofen-type) diffusers on the flashes in order to simulate a bare bulb source. Note that, due to the short distance to subject and low ambient, I used only 2 speedlights instead of 4. The only thing I changed between shots, aside from stacking the diffusers, was the power of the lights in order to keep the exposure constant. Total loss with both diffusers in place was 1.3 stops.

I hope to have someone sit for me soon but, until then, we continue with the fruit theme.

PAD + plate
NIKON D200 75 mm f/7.1 1/200 sec 100 ISO 0.0 EV

Jul 19, 2012 at 12:16 AM
